A 60-year-old male patient underwent laparoscopic radical nephrectomy for a 6.3-cm-sized solid mass in the lower pole of the left kidney, under general anesthesia. His body parameters were weight 84.2 kg, height 175.3 cm, and body mass index 27.4 kg/m2. He had hypertension and diabetes for 20 years, gout for 10 years, and dyslipidemia for an unknown period. Each disease was treated with daily medication including ARB valsartan 80 mg (Diovan; Novartis Pharma Schweiz, Rotkreuz, the Switzerland), adrenergic beta-antagonist carvedilol 25 mg (Dilatrend; Chong Kun Dang Pharmaceutical Corp., Seoul, Korea), calcium channel blocker amlodipine 5 mg (Orodipine; Dong-A ST, Seoul, Korea), oral antidiabetic agent glimepiride 25 mg (Glimel, Dong-A ST), and xanthine oxidase inhibitor allopurinol 100 mg (Zyloric; Samil Co., Seoul, Korea). He had been a smoker and had a drinking history. On radiologic evaluation, both kidneys of the patient were filled with multiple cysts in addition to the mass in the lower pole of the left kidney (Figure 1).

With respect to his laboratory values, parameters indicating renal function were moderately decreased to levels found in the chronic kidney disease 3a stage, as shown below: blood urea nitrogen 23.9 mg/dl, serum creatinine 1.3 mg/dl, and estimated glomerular filtration rate (eGFR) 57.9 ml/min/1.73 m². Also, hemoglobin A1c was increased to 7.9%. His blood glucose values were maintained in the range of 174–194 mg/dl preoperatively. His ECG showed left ventricular hypertrophy.

We induced general anesthesia with propofol 150 mg, supplementary remifentanil infusion at a rate of 0.2 μg/kg/min, rocuronium bromide 50 mg, and intubation with an endotracheal tube with an inner diameter of 8.0 mm, and we maintained anesthesia with desflurane 6 vol%-air-oxygen mixture with FiO2 0.4. The operation was performed in a right down, semi-lateral (30°), and fully flexed decubitus position. We monitored the patient’s physiologic parameters including ECG lead II, noninvasive blood pressure, end-tidal carbon dioxide concentration, central venous pressure (CVP), direct arterial pressure through the right radial arterial catheter, and the arterial blood gas analysis result.

Two hours and thirty minutes from the start of the operation, the vessels and the ureter of the left kidney were ligated successfully. We performed the second arterial blood gas analysis and found severe hyperkalemia with a potassium concentration of 7.0 mEq/L and mild hyponatremia with a sodium concentration of 129.7 mEq/L. Even though there was no change in the ECG, we infused 2 gm of calcium gluconate over 3 minutes, initially. Also, we started to infuse the mixture of regular insulin (RI) 20 IU and potassium chloride 10 mEq in 500 ml of normal saline, at a rate of 40 ml/hr. The crystalloid solutions were changed from Hartmann’s solution to normal saline in order to avoid potassium load. We injected furosemide 20 mg and another dose of 20 mg at an interval of 20 minutes to increase the urine output. After 40 minutes from the detection of hyperkalemia and prompt treatment, the serum sodium/potassium value was 129.6/6.3 mEq/L (Table 1). We extubated the trachea after complete reversal of neuromuscular blockade with sugammadex 200 mg. Total anesthesia duration was 4 hours 50 minutes. Total amount of fluid infused was 1,950 ml of crystalloids and total fluid loss was approximately 350 ml (urine output 250 ml and estimated blood loss 100 ml). In the postanesthesia care unit (PACU), serum sodium/potassium values were 130.5/6.7 mEq/L on arrival and 130.0/5.5 mEq/L before leaving the PACU. The patient was moved to the surgical intensive care unit (ICU).

In the surgical ICU, we used the CVP value and urine output to guide fluid management. The average amount of fluid administered in the ICU was 3,404 ml/day and the urine output was 2,496 ml/day (104.0 ml/hr). Diuretics were used immediately, furosemide 20 mg on the 2nd postoperative day. We analyzed serum myoglobin and creatine kinase levels postoperatively on the day of the operation, under suspicion of rhabdomyolysis. The serum myoglobin level was 648 ng/ml (reference value, <70 ng/ml) and the creatine kinase level was 285 IU (reference value, 0 to 171 IU). The serum potassium level decreased to the normal range at 8 hours after the end of anesthesia. He stayed in the ICU for 2 days and was discharged 11 days after the operation. His serum potassium concentrations were maintained in the range of 4.6–5.0 mEq/L until discharge.

The incidence of hyperkalemia has been reported to be one to 10 per 100 inpatients. This wide range of incidence was due to the wide range of inclusion threshold. In the study by Acker et al. [1], the inclusion threshold for hyperkalemia was a serum potassium level above 6.0 mEq/L, while the inclusion threshold for hyperkalemia was a serum potassium level above 5.3 mEq/L in the report by Shemer et al. [5]. Recently, the incidence of hyperkalemia (serum potassium level >5.0 mEq/L) in hospitalized patients was reported to be 7.3% [2]. When we care for surgical patients as a critical care clinician, we should be aware of the causes of pre-, intra-, and postoperative hyperkalemia, on the basis of the reported incidence of hyperkalemia.

In this case report, the patient had two major preoperative factors of hyperkalemia. These were decreased renal function and drugs that can increase the serum potassium level. There were multiple differently sized cysts in both kidneys of the patient, reducing functionally active parenchyma. Also, hypertension, diabetes, and gout might have contributed to renal function impairment in this patient. His laboratory values indicating renal function were abnormal.

Hyperkalemia was detected during the period between complete renal vessel ligation and removal of the kidney from the abdomen. To suggest that there was a time interval from renal artery clamping to detection of hyperkalemia, loss of whole left kidney function should have contributed to the development of hyperkalemia. Because both kidneys of the patient had multiple cysts, we could not determine which kidney was functionally dominant. The patient’s eGFR value decreased to one-half of the preoperative value after surgery. We supposed that the preoperative function of both kidneys was similarly decreased, and sudden reduction of functioning parenchyma to one-half after left renal artery clamping contributed to decreased potassium excretion.

Nonrenal factors, endocrinal factors, and medications can contribute to the development of hyperkalemia. These factors can disturb the renin-angiotensin-aldosterone system (RAAS), the main hormonal system that regulates renal potassium excretion. Patients with chronic renal disease, most often diabetic nephropathy, may have hyporeninemic hypoaldosteronism [6]. Some drugs that cause RAAS blockade may predispose to hyperkalemia. They include angiotensin converting enzyme inhibitors (ACEi), ARBs, direct renin inhibitors, nonsteroidal anti-inflammatory drugs, and adrenergic beta-antagonists [7]. ACEi/ARB cause hyperkalemia via several mechanisms including decreased aldosterone concentrations, decreased delivery of sodium to the distal nephron, abnormal collecting tubule function, and excessive potassium intake [8]. Among inpatients taking ARBs, the patient-month of hyperkalemia was reported to be 5.4% during the study period, and moderate to fatal hyperkalemia was relatively rare [9]. On the other hand, adrenergic beta-antagonists suppress renin release which is stimulated by catecholamine and decrease aldosterone synthesis, ultimately leading to hyperkalemia [10]. The patient in this case report took valsartan which is an ARB, and carvedilol, on adrenergic beta-antagonist. Both drugs seemed to contribute to the development of hyperkalemia. We were advised to exercise caution while using aldosterone blockade in people with advanced stage 3 nephropathy who have a serum potassium level of 4.5 mEq/L for safety from hyperkalemia [11].

During surgery, potassium may be released from damaged cells as a result of intraoperative tissue damage, ischemia, and rhabdomyolysis. The most common cause of rhabdomyolysis is muscular trauma, and surgery performed in an improper position predisposes to the development of rhabdomyolysis. Rhabdomyolysis after nephrectomy in the lateral decubitus position has been rarely reported [12,13]. A lateral decubitus position, especially a full-flexed flank position for nephrectomy, long operative time, increased body mass index, and extracellular volume depletion are the predisposing factors of rhabdomyolysis after surgery. Additional factors are male sex, younger age, diabetes, chronic kidney disease, and perioperative bleeding. Many factors mentioned above were observed in the patient presented in this case report. Even though the degree of rhabdomyolysis was not severe based on slightly elevated serum creatine kinase and myoglobin levels, rhabdomyolysis itself might contribute to the development of hyperkalemia.

While the diagnostic criteria and treatment of hyperkalemia are well known, confirming the diagnosis of hyperkalemia is not easy. Patients with severe hyperkalemia frequently have normal or abnormal ECG, but these are inconsistent with hyperkalemia. Among patients with potassium levels greater than 6.0 mEq/L, only 46% showed ECG changes. Also, only 55% of the patients with potassium levels greater than 6.8 mEq/L showed changes consistent with hyperkalemia [1]. The reason for challenges in the diagnosis of hyperkalemia is that neither the ECG nor the serum potassium level alone is an adequate index of the urgency of hyperkalemia [14]. In hyperkalemia, the ECG manifestations are generally progressive and proportional to the serum potassium level. But, ventricular fibrillation may be the first ECG abnormality of hyperkalemia; conversely, a normal ECG may be seen in patients with severe hyperkalemia. The patient in this case report did not show any ECG abnormalities to make us doubt the possibility of pseudohyperkalemia. This condition was ruled out after repeated cautious laboratory tests during treatment. It is apparent that we must consider the clinical context while evaluating hyperkalemic patients because neither the ECG nor the serum potassium level alone is an adequate index of the urgency of hyperkalemia.

The recommended guidelines for emergent treatment of hyperkalemia are as follows: (1) serum potassium level greater than 6.5 mEq/L and (2) ECG manifestations of hyperkalemia regardless of the serum potassium level. On this reasonable basis, we treated hyperkalemia through membrane stabilization (calcium gluconate), redistribution (temporary hyperventilation and insulin), and elimination (furosemide). We mixed RI in normal saline instead of dextrose solution because the patient’s blood sugar level was too high. It has been recommended to use insulin without dextrose in hyperglycemic patients [15].

In conclusion, our experience of sudden intraoperative hyperkalemia without ECG changes in a patient who underwent laparoscopic radical nephrectomy reminds us of the possible causes of sudden hyperkalemia. Pre-existing renal insufficiency, preoperative antihypertensive medications including ACEi, ARB, and adrenergic beta-antagonist, and surgery-related factors such as rhabdomyolysis can increase the risk of hyperkalemia.
